CJMCU-29 INA129-HT High Precision Low Power Instrumentation Amplifier Module

Product Description The INA128 HT and INA129 HT are low power general purpose instrumentation amplifiers offering excellent accuracy The versatile three operational amplifier design and small size make them ideal for a wide range of applications Current feedback input circuitry provides wide bandwidth even at high gain A single external resistor sets any gain from 1 to 10000 The INA128 HT provides an industry standard gain equation the INA129 HT gain equation is compatible with the AD620 The INA128 HT and INA129 HT are laser trimmed for very low offset voltage 25 V Typ and high common mode rejection 93 dB at G100 These devices operate with power supplies as low as 2 25 V and quiescent current of 2 mA typically Internal input protection can withstand up to 40 V without damage Texas Instruments high temperature products use highly optimized silicon die solutions with design and processenhancements to maximize performance over extended temperatures The INA129 HT is available in 8 pin ceramic DIP and 8 pin ceramic surface mount packages specified for the 55C to 210C temperature range The INA128 HT is available in an 8 pin SOIC 8 surface mount package specified for the 55C to 175C temperature range Package included 1 x CJMCU 29 INA129 HT High Precision Low Power Instrumentation Amplifier Module
