Brrnoo Worm Gear Motor With Governor Self Locking Mini Turbine Reducer For Robots Electronic Locks

Feature: 1. Using highly precise all metal gears low noise zinc alloy die casting alloy pressure shell stainless iron hardened output shaft. 2. Turbine deceleration all metal gear can cooperate with the governor to control the speed and the motor can be forward and reverse. 3. The motor has a power off self locking function and the maximum bearing capacity of the gear is about 30Kg. 4. This worm gear motor ihas low noise high torsion and the fine craftsmanship extend the service life of the motor. 5. Suitable for electronic locks range hoods display stands robots smart devices barbecue machines nesting machines and entertainment equipment. Specification: Item Type: Worm Gear Motor Material: Iron Plastic Zinc alloy Motor Parameters Voltage: DC 24V Power Range: DC 12-30V Speed Governor Technical Parameters Model: CCM2 Working Voltage: DC10V-30V Control Power: 12Vx3A=36W 24Vx3A=72W Greater Than 24V Maximum 120W Rated Current: 3A Maximum Current: 5A Pwm Pulse Width Adjustment System Range: 5%-95% Potentiometer: Resistance Value B10K Wire Length Approx. 20cm/7.9in Opening Approx. 8mm/0.3in Output Voltage: About 0-100% of The Input Voltage Speed Governor Size: Approx. 74x47x28mm / 2.9x1.9x1.1in Potentiometer Is Used for Speed Regulation Forward and reverse switches are used to control forward reverse and stop Package List: 1 x Motor 1 x Governor 1 x Forward and Reverse Switch 1 x Knob Cap 1 x Washer 1 x Bracket 4 x Mounting Screws Note: Governor 1. The input of the DC motor speed controller is DC and it cannot be directly connected to AC (such as household 220V AC motors) otherwise it will burn out. 2. The positive and negative poles of the DC power supply cannot be reversed otherwise the governor will be damaged. 3. The motor can be positive or negative. When the running direction is inconsistent with the expectation the direction can be changed by adjusting the wire sequence. 4. The potentiometer knob can change the duty cycle of the governor output thereby changing the motor speed. How to use: Motor 1. When using the motor there must be no restraints. 2. The rotation of the shaft may have the opposite effect on the life of the motor. In order to extend the life it is not allowed to overload or hang objects that hinder the rotation at the end of the shaft. 3. Manufactured into an eccentric heavy radiation load which is harmful to the life of the motor. 4. Do not store in surrounding high temperature or extreme humidity and do not place in corrosive gas. 5. D
