Bosch LTC 8782/60-22 Code Translator - Biphase to American Dynamics to Biphase

The LTC 8782 Series Code Translators are accessory units that convert Biphase code to other manufacturers' control codes, or converts other manufacturers' codes to Biphase. Many of the most popular protocol codes are supported, including Pelco, American Dynamics, and Vicon. Fixed and variable speed codes are supported where applicable. The LTC 8782 Series Code Translators have four independent outputs. Removable screw terminal blocks are used for input and output connections. Front panel LEDs indicate the status of power, data receive, and data transmit. The translator comes supplied in an EIA 48 cm (19 in.) rack-mount adapter that can hold up to three units.The LTC 8782/60-22 is an American Dynamics to Biphase code translator to permit control of Biphase receivers from American Dynamics controllers. It receives American Dynamics Manchester code and transmits the appropriate commands in Biphase protocol. Supports full range of Bosch Biphase Aux and preposition numbers. The translator can be programmed by internal switches for the following:• Offset the 64 camera American Dynamic address block to one of 32 Biphase address blocks that support up to 64 cameras each. In large systems, 32 translators can be used to support up to 2,048 cameras.• Accept fixed or variable speed American Dynamics code.Generate fixed or variable speed Biphase code.
