Bosch LTC 8782/60-10 Code Translator - Biphase to Pelco Code, 120 VAC

The LTC 8782 Series Code Translators are accessory units that convert Biphase code to other manufacturers' control codes, or converts other manufacturers' codes to Biphase. Many of the most popular protocol codes are supported, including Pelco, American Dynamics, and Vicon. Fixed and variable speed codes are supported where applicable. The LTC 8782 Series Code Translators have four independent outputs. Removable screw terminal blocks are used for input and output connections. Front panel LEDs indicate the status of power, data receive, and data transmit. The translator comes supplied in an EIA 48 cm (19 in.) rack-mount adapter that can hold up to three units.The LTC 8782/x0-10 is a Biphase to Pelco code translator to permit control of Pelco receivers from Biphase controllers. It receives Biphase code and transmits the appropriate commands in Pelco RS-422 protocol. The translator can be programmed by internal switches for the following: • Support Pelco "P" or "D" output code.• Support up to 256 addresses in "D" code, and 16 or 32 addresses in "P" code.• Support Pelco output baud rate of 2400 in "D" code.• Support Pelco output baud rate of 4800 or 9600 in "P" code.• Support Pelco "turbo speed."
