Bms 3S 80A 12.6V 18650 Lithium Battery Pack Charging Board Overload Short Circuit Protection for Power Bank C

Charging current (same port): less than or to 10A Main circuit conduction internal resistance: less than or to 10MQ Discharge overcurrent protection: 200 +/- 50A Overcharge Protection: Detection voltage: 4.25+0.025V Detection delay: 1000 +/- 500MS Release voltage: 4.15+0.05V Over-discharge voltage protection: Detection voltage: 2.7 +/- 0.1V Detection delay: 1000 +/- 500MS Release voltage: 3.0 +/- 0.1V Balance voltage: Detection voltage: 4.2 +/- 0.025V Detection delay: 100 +/- 50Ms Balance current: 42 +/- 5MA Discharge overcurrent protection: Detection voltage: 100MV Detection delay: 1000 +/- 500Ms Current protection: 200 +/- 50A Short circuit protection: Trigger condition: external short circuit Detection delay: 300Us Release condition: disconnect the load Temperature control protection: Charging working temperature: no Discharge working temperature: no Release condition: recovery within operating temperature Self-consumption: Working power consumption: less than or to 35UA Power consumption during hibernation and overdischarge: 10UA Operating temperature range: -30~+80℃ type: C: 3 strings of 80A with the breakout board colour: silver Material: ABS+metal Size: 137x57x10mm Package Contents: 1 x bms battery charging protection board kit Only the above package content other products are not included. Note: Light and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
