Benro S6 Video Head

The Benro S6 video head is a lightweight accessory uniquely designed for newly released DV, mini DV, pro and civil cameras. Weighing only 2.6lb this video head is perfect for travel or videographers that are on the move but despite its light weight it can support a camera of up to 13.2lbs. Featuring a post-step counterbalance system with four settings (0.0, 4.4, 9.9 and 13.2lbs) and a quick release plate ensures stable image capturing. Unlike other video heads the Benro S6 includes an illuminated bubble level which allows for even and straight videography even at night.
Weighing in at only 2.6 lb itself, the Benro S6 Video Head is a compact video head capable of supporting cameras weighing up to 13.2 lbs. The Posi-Step Counterbalance system has four settings of 0.0, 4.4, 9.9 and 13.2 lb. The S6 has 360° panning rotation and variable tilt drag for smooth camera moves. There are separate Pan and Tilt Lock levers for lock off shots.
The sliding Quick Release (QR) plate helps to balance the camera and the head comes with a safety lock for the QR plate. The S6 Video Head accepts 501PL compatible Quick Release plates, making it easy to find spares or replacements.
The illuminated bubble level (requires CCR1220 Battery - included) helps to level the S6 Video Head, even in the dark. The adjustable Pan Handle can be mounted to either side of the S6 Video Head using the built in mounting rosettes. The S6 Video Head can be mounted to Ball Adapters, Tripods and other Camera supports via the 3/8" threaded female receiver on the magnesium alloy flat base.
Features
Built-in Bubble Level Allows adjustment to prevent uneven pans.
Posi-Step Couter Balance Adjustable counterbalance settings in 2, 4.5 and 6kg steps.
Tilt Drag Knob with Lock Lever Variable control drag with separate lock lever.
Includes a QR Plate Removable QR plate with sliding adjustment for better camera balance.
Interchangeable Pan Bar Handle With angular adjustment, fits on both left and right of head for convenient user control.
QR Plate System with Safety Lock Easy camera mounting and dismount for transport.
Pan Lock Lever Locks Head on 360 degree pan movement.
General
Load Capacity Maximum Load 13.2 lb (6 kg)
Mounting Base 70 mm Flat Base with 3/8" Threaded Female Receiver
Counter Balance System Spring Cartridge
Counter Balance Range 3 Steps 4.4, 9.9, 13.2 lb (2, 4.5, 6 kg) plus zero setting
Center of Gravity Not Specified by Manufacturer
Quick Release/Wedge Plate Yes
Balance Plate Sliding, 1/4" and 3/8" screws QR6 (501PL Compatible)
Tilt Drag Variable
Tilt Range -75 to +90
Tilt Lock Separate Lock Lever
Pan Drag Fixed
Pan Range 360°
Pan Lock Separate Lock Lever
Leveling Bubble/Illuminated Yes/Yes (CR1220 Battery - Included)
Temperature Range -4 to 140°F (-20 to 60°C)
Height 4.5" (115 mm)
Weight 2.6 lb (1.2 kg)
