Beitian BN-383 QMC5883 GNSS Compass GPS Module For APM Pixhawk Naze32 F3 F4 Flight Controller RC FPV Racing Drone

Description Brand Name BeitianItem Name BN 383Specifications Chip CharacteristicsChipM8030 KTFrequencyGPS L1 GLONASS L1 BEIDOU B1 GALILEO E1 SBAS L1 QZSS L1Working ModeGPS GLONASS BEIDOU GALILEO SBAS and QZSS Default GPS GLONASS SBAS QZSS joint positioning For customers with high accuracy requirements it is suggested to use GPS GLONASS SBAS QZSS GALILEO or GPS BEIDOU SBAS QZSS GALILEO joint positioning mode Channel72CH Search channelSensitivityTrack 167dBmRecapture 160dBmCold Start 148dBmHot Start 156dBmPrecisionHorizontal Accuracy2 0 m CEP 2D RMS SBAS assist open space Speed Accuracy0 1m s 95 SA off Time Accuracy1usStart TimeCold Start26sWarm Start25sHot Start1sOutput DataBaud Rate4800bps 921600bps default 9600bpsOutput LevelTTL levelOutput ProtocolNMEA 0183 or UBX the default NMEA 0183 protocolNMEA StatementRMC VTG GGA GSA GSV GLLUpdate Frequency1Hz 10Hz default 1HzFlash4M FLASH you can change the configuration power is not lostWork LimitHeight50 000m maxSpeed515m s maximumGravity Acceleration4g maximumPower ConsumptionVoltageDC 3 0V 5 5V typical 5 0VCurrentNormal 50mA 5 0VPhysical ParameterSize38mm 38mm 10mmWeight10gConnector1 25 pitch 6pin 1 25 pitch 4pinEnvironmentOperating Temperature 40 °C 85 °CStorage Temperature 40°C 105°CCompassCompassBuilt in electronic compass QMC5883LPin Definition NumberNameI ODescriptionCharacteristics1 25 pitch 6pinGNDGGroundGroundTXOUART communication interface TTL levelGPS data output pinRXIUART communicati
