Beitian BN-220T GPS GLONASS Module for APM Pixhawk CC3D Naze32 F3 F4 Flight Controller RC Drone

Beitian BN-220T GPS GLONASS Module for APM Pixhawk CC3D Naze32 F3 F4 Flight Controller RC Drone Specification: Electrical Characteristics Chipset M8030-KT Frequency GPS L1, GLONASS L1, BEIDOU B1, GALILEO E1, SBAS L1, QZSS L1 Receiving Format GPS, GLONASS, BEIDOU, GALILEO, SBAS, QZSS. Default GPS, GLONASS, SBAS, QZSS. Channels 72 Searching Channel Sensitivity Tracking -167dBm Reacquisition -160dBm Cold Start -148dBm Hot Start -156dBm Accuracy Position Horizontal 2.0 m CEP 2D RMS SBAS Enable (Typical Open Sky) Velocity 0.1m/sec 95% (SA off) Timing 1us synchronized to GPS time Acquisition Time Cold Start 26s Warm Start 25s Hot Start 1s Data Output Support Rate 4800bps to 921600bps, Default 9600bps Data Level TTL Level Data Protocol NMEA-0183 or UBX, Default NMEA-0183 NMEA Message RMC, VTG, GGA, GSA, GSV, GLL Update Rate 1Hz-10Hz, Default 1Hz FLASH 4M FLASH, Store the configuration permanently Operational Limits Altitude 50,000m Max Velocity 515m/s Max Acceleration Less than 4g Power Consumption VCC DC Voltage 3.0V-5.5V, Typical: 5.0V Current Capture [email protected] Mechanical Specifications Dimension 22mm*20mm*8mm Weight 8.3g Connector 1.00mm 4pins connector Environment Operating Temp -40 C ~ +85C Storage Temp -40C ~ +105C LED Built-in LED TX LED: blue. The data output, TX LED flashing PPS LED: red. PPS LED not bright when GPS not fixed, flashing when fixed Package Included: 1 x BN-220T GPS GLONASS Module
