Beitian BE-180 GPS Module TTL Level BN-180 Upgrade Version For CC3D F3 RC Drone Airplane

Specifications Brand Name Beitian Item Name BE 180Chip M10050Frequency GPS L1 C A QZSS L1S SLAS BDS B1I B1C Galileo E1B C SBAS L1 C A WAAS EGNOS MSAS GAGANWorking Mode GPS GALILEO SBAS QZSS joint positioning Tracking Sensitivity 166dBmReacquisition Sensitivity 160dBmCold Start Sensitivity 148dBmHot Start Sensitivity 160dBmPosition Horizontal Accuracy 1 5 m CEP 2D RMS SBAS Enable Typical Open Sky Speed Accuracy 0 05m sDynamic Heading Accuracy 0 3 deg1PPS Time Accuracy RMS 30ns 99 60nsCold Start Acquisition Time 27sHot Start Acquisition Time 1sAuxiliary Start Acquisition Time 1sData Output Support Rate 4800bps to 921600bps Default 38400bpsData Output Level TTL LevelData Output Protocol NMEA UBXData Output NMEA Message RMC VTG GGA GSA GSV GLLData Output Update Rate 0 25Hz 18Hz Default 1HzData Output Second Pulse 0 25Hz 10MHz can be configured the default period is 1s and the high level lasts for 100msOperational Altitude Limits 80000mOperational Speed Limits 500m sOperational Acceleration Limits 4gPower Consumption of VCC DC Voltage 3 6V 5 5V Typical 5 0VPower Consumption of Current Capture 50mA 5 0VDimension 18 0mm 18 0mm 6 2mmWeight 4 9gConnector 1 00mm 4pins connectorOperating Temp 40 °C 85°CStorage Temp 40°C 105°CTX LED Blue The data output TX LED flashing PPS LED Red PPS LED not bright when GPS not fixed flashing when fixed Pin Description PINPIN NameI ODescriptionCharacteristic1GNDGGroundGround2TXOU
