Beacon600 2.4GHz Wireless Communication Module UART Serial Port bluetooth 4.0 For Remote Control Smart Home

Item Overview: The Beacon600 is a new bluetooth-compatible 2.4GHz wireless communication module. The module integrates the MCU internally, handles the underlying SPI protocol, and reserves the user interface as a universal UART serial port. The user can connect to the mobile phone bluetooth through this module without operating the underlying layer. It has the same structure as the bluetooth bottom layer, and bluetooth. The broadcast mode is similar, it has a simpler protocol than the universal bluetooth, it is very convenient and fast to use, and has a higher cost performance than bluetooth. Features: - Communicate via bluetooth broadcast and scanning protocol - Serial port transparent transmission, adjustable parameters - Air speed up to 1M bps - Output power up to +3 dBm - Embedded small size - Low power consumption, high cost performance Technical Parameters: Parameter Minimum Typical maximum Unit Condition Operating conditions Operating Voltage 2.8 5 6.5 V Operating temperature -40 25 85 Current consumption Emission current 20 mA Emission current 19 mA Sleep current 11 uA RF parameters Frequency Range 2.4 2.484 GHz Serial port baud rate 1200 9600 115200 bps Transmit power -18 3 dBm Application: - Wireless mouse and keyboard - Wireless Health Sports Products - Wireless remote sensing - Alarm security system - Wireless ranging system Package Included: 1 x 2.4G Wireless Transceiver Module
