Battery Lithium Stable Reliable Lithium Battery Charger Module LCD Display For Lithium Battery For 6-60V Battery

Battery Lithium Stable Reliable Lithium Battery Charger Module LCD Display for Lithium Battery for 6-60V Battery Specification: Features: 1. This Charge Control Module can automatically control battery charging and discharging to batter. 2. LCD display battery voltage charge percentage and charging time at a glance. 3. Suitable for 6-60V battery lithium battery etc. 4. charging time with working status indicator. 5. Support UART serial port set. Specification: Model: XY-L30A XY-L10A Optional Control Current: 30A 10A Control Voltage: DC 6V-60V Suction Cup Diameter: 60mm Control :0.1V Output Type:Direct output Voltage Error:0.1V Dimension: 92x45x2.2mm / 3.62x1.77x0.09in 79x42x18mm / 3.11x1.65x0.71in Function Description: 1 Automatic Charge control function By setting the Upper limit voltage volt-HI: UP ; Lower limit voltage volt-LI: dn ; The relay turns ON and the charger starts charging for the battery when Current battery voltage is less than Lower limit voltage dn . The relay turns OFF and complete an automatic charge when Current battery voltage is more than Upper limit voltage UP . 2 Charge Time Control Function How to enable the time control function? It will enable time control function by setting parameter OP is not 0 after entering the parameter set menu. OP default parameter is: --:--h the default does not turn on time control function; After enable Time Control Function OP is not equal to 0 : Relay will turn ON and the charger starts charging the battery and the system starts timing when Current battery voltage is less than Lower limit voltage dn . Relay will turn OFF and end charging if Current battery voltage is more than Upper limit voltage UP during timing. Relay will turn OFF and end charging if Current battery voltage is less than Upper limit voltage UP but the time OP has ended. Relay will keep ON and charging if Current battery voltage is less than Lower limit voltage dn even though the time OP has ended. Module will automatically turn off the charging time control function. And flashing H:ER on screen to remind users that time parameter settings are unreasonable. Press any key to stop flashing. Note: Time format: 00:59 00 is hours 59 is minutes The maximum time is 99:59 which is about 100 hours. 3 UART communication and parameter settings The system supports UART data upload and parameter setting functions TTL level; UART: 115200 8 1 NO. Function 1 ON Relays Enable 2 OFF Relays Disable 3 Start Start data upload 4 Stop Stop data upload 5 Read Read the parameter setting 6 dw10.0 Set volt-LI: dn 7 up20.0 Set volt-HI: UP 8 xx:xx Set the charge
