Battery Equalizer Balancer Lead Acid Lithium Iron or Nickel Batteries Equaliser

Details: HA01: Use this battery equalizer when you have two or more 12V batteries in series. It is used to keep the voltage of each cell the same. Over time with each charge/discharge cycle the battery voltage will begin to become unbalanced. Each battery will also have a different self-discharge rate. These differences will mean that eventually some batteries in the range may be overloaded while others will be undercharged. The voltage difference increases each time the battery charge/discharge process is repeated. This eventually leads to premature failure of some packs in the battery line. This cell equalizer will equalize/balance the cell voltages when it detects that the voltage difference between the two cells is greater than 20mV. It shunts current from battery (the with the higher voltage) to the other battery (the with the lower voltage). Do this until the battery voltages are almost the same. This will improve battery performance and extend battery life. HA01 main features This HA01 battery equalizer can be used in 24V 36V 48V battery systems. Suitable for multiples of 12V battery (if your battery is not 12V please use HA02) 1 cell balancer for 2x12V in series = 24v 2 cell balancers for 3x12V in series = 36v 3 cell balancers for 4x12V in series = 48v Wiring connection see picture 0-5 amp equalization current between cells. LED indicators showing the balance current of cells A to B and vice versa 10V low voltage disconnect. This means that if the battery is significantly discharged below 10V the cell balancer will stop working easy installation HA01 specification Nominal battery voltage 12v per battery Optimized/Balanced Current 0-5A Self-consumption
