Banana PI BPI R3 Open-source Router Development Board with MediaTek MT7986 Support Wi-Fi 6/6E 2.5GbE SFP Banana Pi R3

Description Banana Pi BPI R3 Router board with MediaTek MT7986 Filogic 830 quad core ARM A53 MT7531A chip design 2G DDR RAM 8G eMMC flash onboard It is a very high performance open source router development board support Wi Fi6 2 4G wifi use MT7975N and 5G wifi use MT7975P support 2 SFP 2 5GbE port and 5 GbE network port Specifications CPU MediaTek MT7986 Filogic 830 Quad core ARM Cortex A53 MT7531 chip designSDRAM 2 GB DDR4On board Storage MicroSD TF card 8GB eMMC onboardGPIO 26 Pin GPIO some of which can be used for specific functions including UART I2C SPI PWM I2S On board Network 5 Port 10 100 1000Mbps EthernetSFP 2 SFP 2 5GbEWifi Wifi 6 4x4 2 4G Wifi MT7975N 4x4 5G Wifi MT7975P Mini PCIE Mini PCIe via USBM 2 interface M 2 KEY M PCIe inerfaceUSB 1 USB 3 0 host 2 USB interface with slot Buttons Reset button WPS botton boot switchLeds Power status Led and RJ45 LedDC Power 12V 2A with DC inSizes 100 5x148mm same as Banana Pi BPI R64 and Banana Pi BPI R2Weight 200gFeatures 1 MediaTek MT7986 Filogic 830 Quad core ARM Cortex A53 MT7531 chip design2 Wifi 6 4x4 2 4G Wifi MT7975N 4x4 5G Wifi MT7975P 3 2G DDR RAM4 8G eMMC flash5 2 SFP 2 5GbE6 5 GbE network port7 POE support optional 8 Mini PCIe via USB9 M 2 KEY E PCIe inerface10 Mciro SD card interfact11 26 PIN GPIOApplication 1 Internet service Router2 Wireless Router3 Wireless Repeater4 Home security Gateyway5 Home Automation6 Nas device7 Network and communication application
