BUYISI Solar Panel Photovoltaic Power Optimiser 600W Photovoltaic Optimiser Controller

Features *Maximum flexibility: Compatible with most brands of photovoltaic modules flexible system design maximize space utilization *Higher output: stabilize the voltage of photovoltaic modules and improve the power generation efficiency when photovoltaic modules are affected *Efficient operation: Solve the problems of photovoltaic flashlight power loss long string design etc. *Intelligence: intelligent optimization and upgrading system which can improve the power generation efficiency of solar panels by 20-30% *Reliable performance: easy installation and operation Specification DC input Max input power: 600W Operation voltage range: 7~60V MPPT voltage range: 7~60V Max input current: 16A Over-current protection: 18A Over-temperature protection: 150С DC output Max output current: 16A Output voltage limit: 42V Max system voltage: 1500V 72-cell module in serial @1500V: 36 pcs 72-cell module in serial @1100V: 26 pcs 72-cell module in serial @1000V: 24 pcs Efficiency Peak efficiency: 99.5% Power loss @5A: 0.9W Power loss @8A: 1.4W Power loss @12A: 2.9W Power loss @15A: 4.5W Power loss @20A: 7.2W General data Dimensions (L×W×H): 103×105.3x21.3mm Weight: 0.65Kg input/output cable length: 500/1000mm input/output cable size: 4mm²(12AWG)/4mm²(12AWG) Terminals: Photovoltaic terminals (compatible) Environmental Protection Rating: IP68/NEMA6 Relative humidity: 0~100% RH Operating temperature range: -40~+65℃ Cooling: Natural cooling Packing list: 1*PV module optimizer Note: 1. The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2. Please allow slight manual measurement deviation for the data.
