BSP/NPT 1'' PVC DN25 Water Electric Valve TF25-P2-C DC12V/24V 2/3/5 Wires 10NM On/Off 15 Sec Metal Gear For Water Control
Technical Details
| Actuator Mode: | With Instruction |
| Brand Name: | Tsai Fan |
| Certification: | IP67, CE |
| Control Wiring: | 2/3/5 Wires |
| Gear Material: | Metal Gear |
| Material: | PVC-U |
| Media: | Water |
| Model Number: | TF25-P2-C |
| on/off time: | 15 Sec |
| Port Size: | DN25, 1'' |
| Power: | DC12V/24V |
| Power Source: | DC |
| Pressure: | Max 1.0Mpa, 10Bar |
| products: | UPVC DN25 Electric Shut Off Valve |
| Standard or Nonstandard: | Standard |
| Structure: | Ball |
| Temperature of Media: | 1-95 Degree C |
| Torque: | 10 Nm |
| using life: | 100,000 Circles |
| Valve Thread Option: | BSP or NPT |
| Valve Type: | 2 Way Ball Valve |
