BLUEROCK Tools Model SL-1.0 Seam Locker Folding Tool for Pittsburgh Seams

BLUEROCK ® Tools Model SL-1.0 Seam Locker Specifications: Lock Capacity: 0.5mm-1.0mm 28-20 gauge Galvanized Steel 26-20 gauge Standard Steel (See other model SL-1.25 for thicker 22-18 gauge steel) Height of Flange (the metal edge to be folded over): 6-11mm ONLY (See other model SL-1.25 for 11-13mm flange height) Material Tensile Strength: 0.02-0.04 Inch Motor Data: 120v 60Hz 11.6 Amps 1400W Standard US Grounded Plug Machine Speed 150RPM Single Speed Gearbox Working Speed: 13-23 ft/min Inner Radius: Min 5.9 Outer Radius: Min 11.8 G. W.: 19 lbs N. W.: 12 lbs The purpose of the SL-1.0 Seam Locker is to fold and close longitudinal Pittsburgh lock joints/seams on ductwork e.g. ventilation ducts housings containers etc. This creates a clean and uniform folded seam. This machine does not create a Pittsburgh seam only folds the seam. The machine will automatically adjust itself for sheet thickness as long as it is within specifications. The quality of the locking seam depends on the height of flange. If flange is too large or too small the lock seam cannot close properly. This is a brand NEW BLUEROCK Tools Seam Locker Model SL-1.0. It comes with a plastic carrying case for protection during shipping. The lock seam can be closed on straight or slightly curved contours The model SL-1.00 is for locking seams 0.5mm-1mm ONLY PLEASE CONFIRM ALL THE SEAM GAUGE & MEASURED SIZE CRITERIA ABOVE BEFORE PURCHASING
