BLDC Three-phase DC Brushless Hallless Motor Controller ESC Motor Driver Board High Power

Note This drive is a DC three phase brushless Hallless control board The motor can work normally without Hall BLDC wide voltage 5 36V high power 350W DC three phase brushless non inductive controllerMotherboard specifications Product Name 380W Brushless DC Motor ControllerModel ZS X11FWorking voltage 6 5 50VDrive current rated 16A plus air cooling 30AMaximum power 380WOvercurrent protection None requires external fuse Stall protection Yes current will drop automatically after stall Over temperature protection Yes power over half when temperature exceeds 100 degrees Maximum speed 224000 RPM 2 pole motor 74000 RPM 6 pole motor 40 000 RPM 12 pole motor 35000RPM 14 pole motor Product size length 63MM width 45MM height 31MMWeight about 76gInterface Description 1 U V W phase wire output is connected to the motor2 5V GND motherboard comes with power supply current does not exceed 300MA 3 VCC GND Motor main power supply external DC power supply 4 SC speed pulse signal output5 DIR forward and reverse control can lead external switch 6 BRAKE brake control external switch can be wired 7 0 5V PWM speed control signal input the on board potentiometer can be used to adjust the speed or an external 0 5V analog quantity PWM duty cycle signal input can be used to adjust the speed by jumper Precautions 1 The power supply circuit on the main board has no fuse It is recommended to add it by yourself The positive and negative poles of the power supply
