BIGTREETECH SKR V1.3 Controller Board + 5Pcs TMC2130 Stepper Motor Drivers + TFT3.5 Touch Screen Mainboard Kit for 3D Pr

Note the Driver included in this kit is in General Mode without WeldingBIGTREETECH SKR V1 3 32 Bit LPC1768 Master Chip CPU Control Board Support Working Mode TMC2208 UART Integrate Keil MDK5 development environment with mainstream development tools Support online debugging more helpful for product development and performance optimization C language development low development threshold Update and configure firmware with SD card easy to operate Support serial wifi Support the functions of power off continuous play material failure detection shutdown etc TMC2130 V3 0 Configuration CFG Microsteps Up to 1 256 MicroPlyer 1 256 Logic Voltage VI0 3 5V Motor Voltage 5 5 46V Motor Phase Current 1 2A RMS 2 5A Peak DIY 2130 V3 0 option is not wired and requires you to solder yourself when using SPI mode Otherwise the stepper motor is ordinary working model Welding method Welding CFG4 to GND CFG5 to VCC Please add the TMC2130 wire together if you need to use SPI model BIGTREETECH SKR V1 3 GitHub Manual https github com bigtreetech BIGTREETECH SKR V1 3https www dropbox com s x3cgq7tqbhk2yfd SKR 20V1 3 Instructions pdf dl 0 More Info about TMC2130 V3 0 https github com bigtreetech BIGTREETECH TMC2130 V3 0Only Marlin firmware can demonstrate the full functionality of SKR V1 3 https github com bigtreetech BIGTREETECH SKR V1 3 tree master firmware smoothieware 2BTFT35TFT3 5 Manual https github com bigtreetech BIGTREETECH TFT35 V2 0 blob
