BCLONG 1-8s Generally Lithium battery power meter display module blue-green two colors

Feature *The power display board that can be used in the nickel -hydride battery of lithium batteries as long as the required voltage is available in the range of the parameter table. How to use: The positive and negative wiring end of the display board is connected to the tested battery positive and negative pole ends. *Battery-type power display select the corresponding pad to tin and you can detect the battery pack voltage corresponding to the 1S-8S which is very convenient. *S1-S8 optional pads can only be connected and 2 or more short connections are allowed at the same time. *Waterproof if you use it outdoors please do waterproof because electronic components need to be used in a dry environment. *The maximum voltage of the module does not exceed 4.3*3 = 12.9V the battery voltage is greater than n × 3.3V and the amount of electricity is bright. N is the number of battery sections. Specification Type: 1-8s Generally Color: blue display green display Installation type: surface paste type Display the number of power numbers: (n represents the number of batteries) 1. When the battery voltage exceeds N*3.3V it will illuminate 1 electricity volume 2. When the battery voltage exceeds N*3.5V it will illuminate 2 yuan in electricity 3. When the battery voltage exceeds N*3.7V it will illuminate 3 pieces of electricity 4. When the battery voltage exceeds N*3.9V it will illuminate 4 pieces of electricity 5. When the battery voltage is less than n*3.3V the 4 display screen will be turned off indicating that the battery power is less than 3.3V and it needs to be charged. Package included 1*Lithium battery power meter display module Note: 1. The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2. Please allow slight manual measurement deviation for the data.
