BAMILL BMS 6S 24V 10A 20A 30A Balance Board Battery Charge Protection Plates Charging

BMS 6S 24V 10A 20A 30A 40A Balance Board Charge Protection Plates Charging Module for 25.2V Lithium Battery Power Bank Ebike Specification: Li-ion 6S 22V 10A/20A/30A BMS Applicable :3.7V or 3.6V lithium battery Connection method:Common Port Over-discharge protection voltage :2.7V±0.08V Continuous working current :10A/20A/30A Instantaneous protection current:25A/40A/50A/70A/90A Overcurrent recovery conditions :charge recovery or disconnect load Short-circuit recovery conditions :charge recovery or disconnect load Overcharge protection voltage :4.25V±0.025V Continuous charging current :10A/20A/30A Charge equalization voltage:4.125V±0.025V Charge equalization current:40mA(maximum value) Charger voltage :25V (recommended) Activation method :(1) B- and P- wires can be short-circuited once (2)Rechargeand activate Work power consumption:≤30uA Main circuit conduction internal resistance:≤50mΩ Temperature range :-40℃ ~ 80℃ Wire break protection: Yes Connecting cable: / Appearance size:96*34*2.8MM other instructions:10A BMS=4MOS 20A BMS=8MOS 30A BMS=12MOS Package: 1x Protection Board Note: 1. Please allowed 1-3mm differences due to manual measurement thanks. 2. Due to the difference between different monitors the picture may not reflect the actual color of the item.
