Audio 2000s AWM6152 Dual-Channel Infrared Rechargeable Wireless Microphones
The Audio2000'S AWM6152 professional dual-channel infrared rechargeable wireless microphones is an infrared wireless microphone system with the recharge mechanism built at the bottom of the handheld microphone (AWX6150). The AWX6150 can be inserted onto the microphone recharge sockets on the ACC6152-01 microprocessor controlled microphone recharger.Any rechargeable AA batteries can also be inserted to the battery recharge sockets on the ACC6152-01 to be recharged.When the recharging process is in progress, the recharging LED indicator remains on. The recharging LED indicator will be turned off when the rechargeable AA batteries are fully charged.There are two 1/4" audio outputs, audio output A and audio output B. If only either the audio output A 1/4" jack or the audio output B 1/4" jack is connected to an 1/4" plug, the used audio output 1/4" jack will be a mixed output jack containing both the audio output A signal and the audio output B signal. If each of the audio output A 1/4" jack and the audio output B 1/4" jack is connected to an 1/4" plug, both audio output 1/4" jacks become independent outputs where the audio output A 1/4" jack contains only the audio output A signal and the audio output B 1/4" jack contains only the audio output B signal.There are four infrared sensor input RCA jacks. Each RCA jack can be connected to a remote infrared sensor via a shielded RCA cable. Depending upon the applications, up to four remote infrared sensors can be connected to these jacks simultaneously and used to enhance the AWM6152 reception capabilities. In the system, one additional remote infrared sensor and one extension cable are included. If more than one remote infrared sensor needs to be used, the remote infrared sensors and the extension cords can be purchased separately.At the bottom of the AWR6152 infrared receiver, there is a line/microphone output selector. This selector is used to set the audio output levels. When the selector is set at the "LIN" position, the output signal is selected to be at the line level and the audio outputs can be connected to appropriate line inputs. When the selector is set at the "MIC" position, the output signal is selected to be at the microphone output level and the audio outputs can only be connected to the microphone inputs.At the back of the AWX6150 microphone battery housing, there is an infrared transmission power selector. This infrared transmission power selector is used to adjust the infrared transmission power levels. It is preset to the low level. When the infrared reception by the infrared sensors becomes insufficient in an application, the infrared transmission power selector can be set to the high level. When the infrared transmission power selector is set at the high level, the battery operation time will be substantially reduced.- AWR6152 Receiver -• Infrared Wireless System• Dual Channels• Two Audio Level Controls• Two Independent 1/4" Outputs or One Mixed 1/4" Output• Four Independent Infrared RCA Inputs• Selectable Line Outputs (LIN) or Microphone Outputs (MIC)Front Panel Functions• Power On LED Indicator• Infrared Sensor• Channel A RF Signal Indicator• Channel A Audio Signal Indicator• Channel A Volume Control Knob• Channel B RF Signal Indicator• Channel B Audio Signal Indicator• Channel B Volume Control KnobRear Panel Functions• Audio Output A 1/4" Jack• Audio Output B 1/4" Jack• Infrared Sensor Input Jacks• DC Power Input Jack• Power On/Off Button• Line/Microphone Output Selector• Power-On LED Indicator- AWX6150 Transmitter -• Infrared Wireless Transmitter• Recharge Mechanism at the Base of the Handheld Microphone with 2 X AA Batteries• Selectable Infrared Transmission Power• Low Battery LED Indicator
