Aokid DDM36SC 220V 50/60Hz Backlight Button Reset Single Phase Din-rail Energy Meter Industrial control LCD Display Easy Installation Durable

Aokid DDM36SC 220V 50/60Hz Backlight Button Reset Single Phase Din-rail Energy Meter Industrial control LCD Display Easy Installation Durable
Aokid
артикул: 544281587
СОГЛАСНО НАШИМ ДАННЫМ, ЭТОТ ПРОДУКТ СЕЙЧАС НЕ ДОСТУПЕН
$16.89
Доставка из: США
   Описание
Specifications: 35mm standard din-rail installation is in line with standard DIN EN50022. Bipolar width (modulus 17.5mm) is in line with DIN43880 standard. It has standard configuration 5+1 backlit LCD display (99999.1KWh). LED is the energy pulse power supply signal (red). One-way measurement of single-phase two-wire has power consumption which has nothing to do with the direction of load current flow and is comply with GB/T17245.321-2008 standard. S-type wiring is standard configuration while U-type wiring is optional. This product has the function of display electricity voltage current frequency power factor. Made of high quality material it is durable anti-rust and easy to use. Item Name: Electric Energy Meter Material: Flame Retardant Plastic Type: 1#: 5-30A 2#: 10-40A 3#: 15-60A 4#: 20-80A 5#: 5-80A Model: DDM36SC Accuracy: Level 1 Reference Voltage: 220V 50/60Hz Current Specifications: 5-30A/10-40A/15-60A/20-80A/5-80A Indicate Current Specification: Reference Current (Maximum Current) Insulation Performance: AC Voltage 4KV 1 Minute 1.2/50us Waveform Impulse Voltage 6KV Display Mode: LCD with Backlight Display Installation Method: Din-rail Installation Wiring Mode: Bottom In And Top Out/Top In And Bottom Out Features: LCD Display Easy Installation Durable Size: 8cm x 7cm x 4cm/3.15 x 2.76 x 1.57 (Approx.) Notes: Due to the light and screen setting difference the item s color may be slightly different from the pictures. Please allow slight dimension difference due to different manual measurement. This model does not have the reset function. Package Includes: 1 x Electric Energy Meter
