Antenna Meter SWR 1-60MHz Antenna Analyzer For Measurement

Antenna Meter SWR 1-60MHz Antenna Analyzer for Measurement Specification: Description: This is a SWR analyzer for ham hobbyists. With 5 buttons Mode Band Config Scan Up Down you can selects operation mode band and extended functions. It is powered by DC 12 to 14V 500mA external power with 2.1mm power jack and can be used to measure antenna electrical parameters SWR impedance resistance + reactance capacitance inductance feed-point impedance ground loss etc. Features: SWR usable measurement range of this analyzer is 1.0 to 9.99. step size: user configurable increments of 100Hz 1KHz 10KHz and 100KHz. Powered by DC 12 to 14V 500mA external power with 2.1mm power jackcenter pin positive just connect the power and then work. 5 operation buttons are easy and convenient to operate. You can selects operation mode band and extended functions. Beautiful and simple designed black case would the antenna analyzer from external damage. This would be a great SWR antenna analyzer for ham hobbyist or professionals. Specifications: Frequency Generation & Control: 1 - 60 Mhz Source Impedance: 50 Ohms Stability: +/- 100 ppm Purity: Harmonics down >- TBD dB beyond 60 MHz Step Size: User configurable increments of 100 Hz 1 kHz 10 kHz and 100 kHz SWR Usable Measurement Range: 1.0 to 9.99 Impedance: Approx. 5 to 2000 ohms RF Output: 2.0 Volts pp typ Power Supply: Powered by external 12 to 14V DC 500mA Push Buttons 5: Mode Band Config Scan Up Down Switch: Power On Connectors: RF USB: Mini-B receptacle External Power: 2.1mm Power Jack center pin positive Size: 150 x 90 x 40mm / 5.9 x 3.54 x 1.57 Applications: 1. Measure antenna electrical parameters: SWR impedance resistance + reactance capacitance inductance 2. Measure feed-point impedance 3. Measure ground loss 4. Adjust antenna tuners and determine loss 5. Measure inductors and capacitors 6. Measure coax transmission line SWR length factor approximate Q and loss resonant frequency and impedance 7. Measure and determine settings for tuning stubs: SWR approximate Q resonant frequency bandwidth impedance 8. Determine characteristic impedance of transmission line 9. Coaxial Cable Loss 10. Determine antenna tuner loss 11. Measure balun loss 12. Measure inductor Q 13. Estimate quartz crystal parameters 14. Measure loop resonance and SWR Operation Button Function: Mode: Selects operation mode impedancedefault complex impedance capacitance and inductance BAND: Select band from any of the available bands 160M to 6M CONFIG: Provides menu for configurations and extended functions PC Link step size setting suspend timeout setting calibration and software upgrade SCAN: Pressing this control initiates a scan of frequencies of the selected BAND. Scan exits to impedance mode showing the 2:1 bandwidth and the resonant point o the antenna CANup: Increase frequency and used to cancel operation for CONFIG menu VALdown: Decrease frequency and used to validate operation for CONFIG menu Package Includes: 1 x AnalyzerPower supply is not included Note: Please note that the new type and old type of this product will be
