Aluminum Alloy 35mm Hinge Jig with Clamp Forsnter Drill Bit Drilling Guide Hole Punch Locator Kit Woodworking Cabinet Do

Description Aluminum Alloy 35mm Hinge Jig with Clamp Drill Guide Hole Punch Locator Kit Woodworking Cabinet Door Installation Hole LocatorNo Need for Extra Clamp Including Clamp Itself Quick and Fast Locating Specification Product name 35mm Hinge Punch Jig Drilling Guide LocatorColorBlackMaterialAlloyEdge Distance Adjust3 4 5 6mmQuantity1pc Hole Punch Locator SetFeatures Handle clamping plate There is no need to clamp it vigorously it has a fastening device CNC fine grinding Thickening alloy knife blade Application The hinge opening is suitable for 35mm hinges no need for measuring Instructions 1 The puncher is fixed on the board it is recommended to be 30mm from the edge 2 Adjust the distance between the limit ring and the drill sleeve to determine the depth of the hole3 Drill the threaded rod hole and insert the round raft4 The puncher is attached to the round raft and then clamps the board5 Start drilling6 Lock the wood board when drilling the eccentric wheel hole please ensure that the drill bit is perpendicular to the drill sleeve by 90 degrees Package included 1pc xHole Punch Locator1pc xAllen Socket2pc xWrench1pc x35mm Drill BitMore details
