Air Manifold Pure Aluminium G1/2 Inlet Pneumatic Block No Leakage G1/4 Outlet 40x40mm For Distribution SY40-02-3F SY40-02-4F

Air Manifold Pure Aluminium G1/2 Inlet Pneumatic Block No Leakage G1/4 Outlet 40x40mm for Distribution SY40-02-3F SY40-02-4F Specification: Item Type: Air Manifold Material: Aluminium Pressure Resistance: 1.0MPA 10kgf/cm Working Pressure: 0~0.9Mpa0~0.92kfg/cm² Adaptive Temperature: 0~60 degrees Celsius Model Total LengthApprox. Way and Port Length x WidthApprox. Main Air LineApprox. Split PortApprox. Split Port Centre ApertureApprox. Mounting Hole DiameterApprox. Vertical Mounting Holes Centre SpacingApprox. Horizontal Mounting Holes Centre SpacingApprox. SY40-02-3F 120mm / 4.72in 3 Way 5 Port 40 x 40mm / 1.57 x 1.57in G1/2 20mm / 0.79in G1/4 12mm / 0.47in 35mm / 1.38in 5.5mm / 0.22in 29mm / 1.14in 35mm / 1.38in SY40-02-4F 155mm / 6.1in 4 Way 6 Port 70mm / 2.76in Package List: 1 x Air Manifold Note: 1. Do not unplug and insert the air tube frequently during the use of the connector which will affect the service life of the connector and air tube. 2. The pipe inserted into the joint needs to be inserted to the bottom of the joint to avoid the possibility of air leakage. 3. When pulling out the air tube first confirm that there is no pressure in the tube then press the end of the joint to the end and pull out the air tube.
