Ac Dc Led Gate Flashing Light Lamp For Swing Sliding Gate

Features: Antenna This is used to extend the effective distance of controller Waterproof and dustproof It is made of plastic material IP 54 Notice： 1 Terminal 1 is for connectino thepower input; working voltage is 12-265VAC/DC. 2 Terminal 2 is for connecting the antenna of RF controller to extend the effective working distance Instruction: After power the lamp on LED will start fashing in 1HZ(default setting). sW1 is the switch for selecting flashing or on mode of the lamp.CAP short connectsthe 2 pins; the lamp is in flashing mode. Remove the CAP from 2 pins the lamp is inon mode. Be Careful the whole board includes the components are with high voltage. Alwaysmake sure power is off before you open the cover Installation： Open the package; take out the products and all the accessories. Removing the antenna by rotatinganticlockwise. Mark 2 holes on the wall by using the fixing hole of bracket. Drilling two 6mm diameter holes and one 10mm diameter hole. Then put the expansion plug intothe 6mm diameter holes. Put the wires through 10mm diameter hole. Put the power wire and antenna through the cable holes in the holder. And fix the holder to thewall by provided 4mm*30mm self-taping screws. Connect the wire and antenna to the correct terminals. Put the cover back and make sure the cover is fastened with the bottom base without any gap.Then screw the antenna up and turn clockwise to make it tight. Always install the holder and lamp upright to the ground. Horizontally installation may cause therain go inside the lam and damage the board. Specification: Working voltage: 12-265V AC/DC Loading capacity: 1.5W Weight: 156g Flashing frequency: 1Hz Installation method: Vertical/horizontal Working temperature: -20°C~+60°C Protection level: IP54 Size: 60*85mm Package Contents: 1* Light Note: 1. The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2. Please allow slight manual measurement deviation for the data.
