AVMatrix Aviatrix MSS1611-S 1RU Rackmount 16 x16 3G/HD/SD-SDI Seamless Matrix Switcher
MSS1611-S is a perfect solution for large broadcast project. The compact SDI routing switcher features 16 inputs and 16 outputs, redundant power connections and an elegant machined metal front panel with 2.2 inch LCD for routing label display. Routing can be performed by direct button selection and the spin knob controller.
The 3G-SDI seamless matrix switcher supports standard 3G/HD/SD SDI rates, automatic bypass of non-standard rates between 270Mbit/s and 3Gbit/s. Built-in frame synchronizer support simultaneous input of signal of different resolution frame rates, which can realize seamless switching without black screen. It can conveniently controlled by front panel button, PC software via LAN/RS-422.
FeaturesSeamless Switching
Built-in frame synchronizer supports simultaneous input of signals of different resolution frame rates, which can realize seamless switching without black screen. Signal switching is clean without the need for external REF synchronization.
Up and Down ScalingMSS1611-S is compatible with multiple format signal inputs in different resolutions and frame rate with auto detection technology. User can set the output format up or down according to their need.
Control Method
MSS1611-S is coming with a full control panel that almost all functions can be set throught this panel via the dedicated buttons, menu knob and 2.2 LCD screen. And with the free PC software via Ethernet, user can control it on a windows PC conveniently.Compact Design & Reduntant PowerThe use of premium components coupled with dual redundant power supplies ensures device works fine even when the mainpower supply encounters problems.
