ASUS RT-AC68U Smart WiFi Router AC1900 Dual Band Gigabit Router

Features:
Dual-band with the latest 802.11ac 3x3 technology for combined speeds of up to 1900 Mbps
1GHz Dual-core CPU enables smart multitasking by dedicating separate lanes for Wifi and USB data
Monitor and manage your network with ease from your mobile device using the intuitive ASUS Router App
AiProtection Powered by Trend Micro provides multi-stage protection from vulnerability detection to protecting sensitive data
AiMesh Supported - Connect to other compatible ASUS routers to create a powerful and flexible whole-home Wi-Fi network
The RT-AC68U also features dual USB ports for file, printers and 3G/4G modems sharing and a USB 3.0 port for up to ten times faster data transfers than USB 2.0.
Specification:
Model
RT-AC68U
Network Standard
IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IPv4, IPv6
Product Segment
AC1900 ultimate AC performance : 600+1300 Mbps
Coverage
Large homes
Data Rate
802.11n : up to 450 Mbps
802.11n TurboQAM : up to 600 Mbps
802.11ac : up to 1300 Mbps
Antenna
External 4 dBi antenna x 3
Transmit/Receive
MIMO technology
2.4 GHz 3 x 3
5 GHz-1 3 x 3
Memory
128 MB Flash
256 MB RAM
Operating Frequency
2.4 GHz / 5 GHz
Encryption
64-bit WEP, 128-bit WEP, WPA2-Personal, WPA-Personal, WPA-Enterprise , WPA2-Enterprise , WPS support
Firewall Access Control
Firewall：SPI intrusion detection,DoS protection
Access control：Parental control, Network service filter, URL filter, Port filter
Management
UPnP, IGMP v1/v2/v3, DNS Proxy, DHCP, NTP Client, DDNS, Port Trigger, Universal Repeater, System Event Log
WAN Connection Type
Internet connection type : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP
Multicast Proxy support
Multicast Rate Setting support
Ports
RJ45 for 10/100/1000/Gigabits BaseT for LAN x 4, RJ45 for 10/100/1000/Gigabits BaseT for WAN x 1
USB 2.0 x 1
USB 3.0 x 1
Features
Airtime Fairness
Adaptive QoS
AiProtection
Parental Control
Guest Network : 2.4 GHz x 3, 5 GHz x 3
VPN server :IPSec Pass-Through, PPTP Pass-Through, L2TP Pass-Through, PPTP Server, OpenVPN Server
VPN client : PPTP client, L2TP client, OpenVPN client
Mac OS Backup
Enhanced media server (AiPlayer app compatible)
-Image : Jpeg
- Audio : mp3, wma, wav, pcm, mp4, lpcm, ogg
- Video : asf, avi, divx, mpeg, mpg, ts, vob, wmv, mkv, mov
AiCloud personal cloud service
3G/4G data sharing
Printer Server
-Multifunctional printer support (Windows only)
- LPR protocol support
Download Master
- Support bt, nzb, http, ed2k
- Support encryption, DHT, PEX and magnet link
- Upload and download bandwidth control
- Download scheduling
AiDisk file server
-Samba and FTP server with account management
Dual WAN
IPTV support
Roaming Assist
Button
WPS Button, Reset Button, Power Button, Wireless on/off Button
LED Indicator
Power x 1
Wi-Fi x 2
LAN x 4
WAN x 1
USB x 2
Power Supply
AC Input : 110V~240V(50~60Hz)
DC Output : 19 V with max. 1.75 A current
Plug: CN plug with 2 pins, could be used as US plug
OS Support
Windows 10/Windows 8.1/Windows 8/Windows 7/Windows Vista/Windows 2000/Windows ME/Windows XP/Windows Server 2003/Windows Server 2008/Mac OS X 10.1/Mac OS X 10.4/Mac OS X 10.5/Mac OS X 10.6/Mac OS X 10.7/Mac OS X 10.8/Mac OS X/Linux Kernel (Support Ubuntu only)/Linux
Dimensions
220 x 83.3 x 160 ~ mm (WxDxH) (Without Bezel)
Operation mode
Wireless router mode
Range extender mode
Access point mode
Media bridge mode
Note:
1.Specifications and features vary by model, and all images are illustrative. Please refer to specification pages for full details.
2.PCB color and bundled software versions are subject to change without notice.
3.Brand and product names mentioned are trademarks of their respective companies.
4.The actual transfer speed of USB 3.0, 3.1, 3.2, and/or Type-C will vary depending on many factors including the processing speed of the host device, file attributes and other factors related to system configuration and your operating environment.
5.Actual data throughput and WiFi coverage will vary from network conditions and environmental factors, including the volume of network traffic, building material and construction, and network overhead, result in lower actual data throughput and wireless coverage.
6.Quoted network speeds and bandwidth based on current IEEE 802.11ac
