ARGON 18 E117 Tri Disc Ultegra DI2 - Black Matte/Gloss

The New Reference Point
For many, the E-117 Tri Disc is the obvious choice for their first dedicated triathlon bike. And since aspiring triathletes don’t always come from a cycling background, disc brakes provide increased confidence as they dial-in their TT position. The E-117 Tri Disc will also prove to be a great choice for more experienced triathletes eager to own a reasonably priced triathlon bike, which they can build up by investing in race-day spec of their choice, such as high-end carbon wheels.
Ideal for
The committed age-grouper with a serious PB goal who wants the ultimate in handling and confidence.
The perfect blend of handling and stiffness
We believe a good fit is the key to optimal performance. Argon 18’s proprietary 3D System is an integrated solution that extends the headtube for more flexible positioning options. Three headtube positions are possible for every frame size, increasing stiffness by 5% at 15mm and 11% at 25mm, versus traditional spacers. It allows also a larger fit windows (60mm of stack adjustment compared with 30 for a traditional setup). With this system, the handlebar height can be perfectly adjusted to meet the needs and preferences of every rider.
Get aero
Tri and TT bikes prioritise aero performance, and the geometry of these bikes reflects this. To allow the rider to achieve an aggressive aero position, the seat tube angle is much steeper than on a traditional road bike. This geometry is designed to put the rider in a more forward position. Not only does this help with aerodynamics, it also can help save a triathlete's legs for the run, as it places less stress on the quadriceps. While a TT rider doesn't have to worry about running a marathon after the ride, the same aggressive aero positioning is required to shave precious seconds off the course. Argon 18's triathlon and TT geometry maximises performance while allowing riders to dial in their perfect fit to maintain that position throughout the race.
Find Your Fit
The Argon Fit System is designed to provide riders of all sizes with consistent performance and optimal positioning. Regardless of your build, gender or your riding style, our frames are designed so that your fit will always be efficient and comfortable, ensuring the ultimate in handling. We offer sizing from XXS to XL in all of our road bikes, and XS to XL in our Tri bikes, with each size approached individually from a design and performance perspective. While a lot of manufacturers optimise performance and weight targets for a medium size frame and simply scale up or down, we assess the performance of each size based on the individual character of that particular geometry. For example, even our largest frames have exceptional stiffness without excess weight, to avoid the 'dead' feel found in some XL frames. XS and XXS retain their inherent lightweight qualities, but without excess stiffness, avoiding harsh ride quality.
Best-in-Class Bikes without Breaking the Bank
We want everyone to experience the true essence of Argon 18 bikes. Newcomers to the sport or seasoned cyclists on a budget choose our Cyclosportif level models because of their proven design platforms, carbon layup derived from our Pro-level models, and performance-oriented handling and ride quality.
SPECIFICATIONS
Headset
37E-A + 3D WITH TH-881-1
Stem
Profile Design 1/Seventeen
Handlebar Profile Design Wing/10a Base Bar
Bar Tape Prologo Plaintouch Black
BB (Bottom bracket) Shimano SM-BB72
Brake lever TRP HD-T910
Cassette Shimano Ultegra R8000 11/28
Chain KMC X11EL
Crankset Rotor VEGAST 52/36
Front derailleur Shimano Ultegra Di2 R8050
Rear derailleur Shimano Ultegra Di2 R8050
Rotor TRP TR160-25 160mm / TRP TR160-25 140mm
Saddle ISM PR1.0
Shifters Shimano Dura Ace R9160 Di2
Tires Vittoria Rubino Pro TLR G+700x25c
TT Bar Profile Design Sonic/Ergo/35A 400mm
Wheelset Vision Team TC 35
Size
Seat Tube (c-c)
Seat Tube (c-t)
Top Tube Length
Head Tube Length
Chain Stay Length
Seat Tube Angle
Head Tube Angle
Stand Over Height
Wheel Size
Stack
Reach
L
-
546
527
139
413
78.0
72.0
805
700c
543
409
XL
-
573
545
166
413
78.0
72.0
831
700c
568
422
XS
-
461
492
84
413
78.0
72.0
730
700c
491
385
M
-
516
517
111
413
78.0
72.0
777
700c
516
405
S
-
500
504
95
413
78
72
762
700c
501
395
