APO-D1 15V-24V Dual-Channel Speed Controller 10Ax2 Three-Function DC Brushed Motor ESC Speed Controller

Parameter Product Name Motor Speed ​​ControllerRated input voltage 5V 24V DCStandby current Less than 20mAAverage use current 10Ax2 10A per channelESC mode model airplane remote control 1ms 2ms pulse width 50HZMCU mode 0 100 ratio rate 500Hz 16kHzPotentiometer mode 0v 5V input voltage 2 45V 2 55V motor stops Limit input voltage range 5V 24V DC MAX Pulse peak current 50Ax2 MAX Material PCB metalColor RedWeight 16 5gSize 48 5 x 41 5 x 15mmApplication Motor speed control Motor forward and reverse control Adjustable current limitElectronic adjustable potentiometer single chip microcomputer can control wide voltage input range in any waySpeed ​​control and commutation control of DC brush motor Potentiometer controls the motor forward and reverse rotation and commutationSingle chip microcomputer controls the forward and reverse rotation and commutation of the motorSemiconductor refrigerator temperature adjustment and commutation control Speed ​​regulation and commutation control of coreless motorPackage included 1 x APO D1 dual channel motor speed controller
