APM Pixhawk XL-MaxSonar EZ4 Ultrasonic RC Rangefinder MB1240

APM Pixhawk XL-MaxSonar EZ4 Ultrasonic Range Finder MB1240 The XLMaxSonarEZ4 has the highest noise tolerance and narrowest beam of any of our indoor sensors. The sensor is designed and calibrated to provide reliable range information to large targets even in environments with strong acoustic or electrical noise sources. The sensor is small in size, yet the high output acoustic power combined with continuously variable gain, real-time background automatic calibration, real-time waveform signature analysis, and real-time noise rejection algorithms results in virtually noise free distance readings for most users. This holds true even in the presence of many of the various acoustic or electrical noise sources. The XLMaxSonarEZ sensor line is factory calibrated to match the sensor beam patterns and provides a long range detection zone. The XL-MaxSonar-EZ4 performance to large targets is only beaten by the MB7052. Description: - Dimension: 22*20*25mm - Weight: 6.1g - Distance range: 0-7.65m - 0-20cm output is 20cm - Resolution: 1cm - Power consumption: 3.4mA@5V, [email protected] - Work voltage: 3.3-5V - 42KHz - 10hz read speed ratio - Inner/external trigger - Support three interface: TTL, Vcc, PWM output Product Specifications Resolution of 1 cm 10Hz reading rate 42kHz Ultrasonic sensor measures distance to objects RoHS Compliant Read from all 3 sensor outputs: Analog Voltage, RS232 Serial, Pulse Width Virtually no dead zone, objects closer than 20 cm range as 20 cm Operates from 3.3-5.5V Low 3.4mA average current requirement Small, light weight module Designed for easy integration into your project or product Operational Temperature from 0C to +65C (32F to +149F) Real-time automatic calibration (voltage, humidity, ambient noise) Firmware filtering for better noise tolerance and clutter rejection 200,000+ Hours Mean Time Between Failure Narrowest beam of the XL-MaxSonar-EZ products Highest noise tolerance of the XL-MaxSonar-EZ products Great for large target applications Maximum range of 765 cm (300 inches) Hardware gain of 250 Package Includes: 1 * APM Pixhawk XL-MaxSonar EZ4 Ultrasonic Range Finder MB1240
