ANENG Digital Clamp Meter AC/DC Current Clamp True-RMS Multimeter Auto-Ranging Multi Tester with Amp Volt Ohm Inrush Current Resistance Capacitance Continuity Diode Temperature Frequency NCV Tests for Automotive Electronic HVAC Tech

features loud audible beep for NCV and live line detection, 1.04-inch jaw opening, auto-ranging, true-RMS, 15-minute auto-off, data hold, flashlight, and more.
Features:
MULTI TESTER: Measures AC/DC current, AC/DC voltage, inrush current, non-contact AC voltage (NCV) detection, live/zero line detection, resistance, diode, capacitor, temperature, and frequency.
LOUD BEEP: NCV sensor and live/zero line detector send out audible and visual alarm once AC voltage detected.
PRECISION MULTIMETER: Give an accurate reading on home appliances, cars, electronics, HVAC and more.
WIDE JAW OPENING: Up to 1.04 inches(26.6mm) jaw opening is wide enough to clamp on wire without disturbing circuit.
EASY TO USE: Offers you with auto-ranging and manual ranging mode, extremely simple to use.
SAFE AND RELIABLE: Provided with overload protection and 1000V, 10A test leads, safe and reliable to use.
AUTO-OFF: Automatically shut down if no operation in 15 minutes, and beep when it shut-off.
MORE FUNCTIONS: Features data hold, flashlight, Celsius/Fahrenheit degree, low battery indicator and more.
Note:
*MUST read the user manual carefully before use for safety.
*Battery not included.
Parameters:
Max. Display: 6000 counts
Auto-ranging: yes
True-RMS: yes
Function
Range
Resolution
Accuracy
Max value
Frequency
response
DC Voltage
6V
0.001V
(0.5%+3)
600V
60V
0.01V
600V
1V
AC Voltage
6V
0.001V
(1.0%+3)
600V
40Hz~1kHz
60V
0.01V
600V
1V
DC Current
60A
0.01A
(2.0%+3)
600A
40Hz~1kHz
600A
0.1A
AC Current
60A
0.1A
600A
0.1A
Resistance
6kΩ
0.001kΩ
(1.5%+3)
60MΩ
40Hz~1kHz
60kΩ
0.01kΩ
(0.5%+3)
600kΩ
0.1kΩ
6MΩ
0.001MΩ
60MΩ
0.01MΩ
(1.5%+3)
Capacitance
6nF
0.001nF
(5.0%+20)
60mF
40Hz~1kHz
60nF
0.01nF
(5.0%+20)
600nF
0.1nF
(2.0%+5)
6μF
0.001μF
60μF
0.01μF
600μF
0.1μF
6mF
0.001mF
(5.0%+5)
60mF
0.01mF
Frequency
6.000Hz
0.001Hz
(0.1%+2)
1.000MHz
40Hz-1kHz
60.00Hz
0.01Hz
600.0Hz
0.1Hz
6.000kHz
0.001kHz
60.00kHz
0.01kHz
600.0kHz
0.1kHz
6.000MHz
0.001MHz
10.00MHz
0.01MHz
Diode
Continuity
Inrush Current
Peak hold
Temperature
(-30~1000)℃
1℃
(2.5%+5）
1000℃
(-22~1832)℉
1℉
1832℉
