ANCEL S100 EVAP Smoke Machine Fuel Pipe Diagnostic Car Smoke Leak Auto Leak Smoke Detector

How to do leakage test? 1. Attach the hook to the device. 2. Attach the workshop air adapter to the unit. 3. Plug the power cord into the power outlet. 4. Screw the smoke hose to the unit. 5. Fill smoke oil (mineral oil based) into the unit via the refill opening on the top. (Note: The oil level must not be higher than the level indicator. ) 6.Connect the factory air supply. 7.Connect the vehicle s 12V power supply. 8. Introduce workshop air into the unit. 9. 9. Turn the flow control knob counterclockwise to open the air flow. 10. Turn on the power on the back of the unit then the unit will start to generate smoke. 11. Introduce the smoke into the system FULL SYSTEM DIAGNOSTICS DON T MISS ANY LEAKS. EVAP SYSTEM TEST: Leakage in the fuel evaporation system causes fuel vapour to escape into the atmosphere resulting in waste and pollution or unstable engine idling. EXHAUST SYSTEM TEST: Uncleaned harmful gases escaping into the atmosphere or increasing the noise of the vehicle are the main disadvantage when leaks occur in the exhaust. FUEL TANK SYSTEM TEST: If there are gaps in the fuel tank and pipes caused by improper installation or insufficient sealing of the fuel tank cap it may cause leaks in the fuel tank system. TEST OF VARIOUS PIPE CONNECTIONS: Smoke test of brake hoses power steering hoses cooling system hoses air conditioning system hoses turbocharger hoses fuel hoses intake and exhaust system hoses etc. CAR SEALING TEST: Poor sealing of the car can lead to many inconveniences such as it is not warm and dusty not soundproof not waterproof etc. CRANKCASE SYSTEM TEST: Excessive pressure or corrosion of the crankcase is the main reason why the crankcase seal is damaged and oil leaks. INTAKE SYSTEM TEST: A leak in the intake system will result in inadequate intake of the car engine leading to low engine performance. TURBO TEST: The leakage of coolant would cause the engine to indicate a high water temperature. WHY DO YOU NEED A S100 SMOKE MACHINE? 1.Unmetered air entering an engine will cause all sorts of lean conditions. You cannot see the leaks without the help of smoke. A vacuum line can just become porous over time but look ok. O-rings can become hardened and no longer seal. Plastic parts can be separated or cracked. 2.Exhaust leaks can be bad for your health and can cause backfiring in carbureted cars. You can use the S100 smoke machine to help find exhaust leaks without running the engine and gassing yourself. 3.You can smoke test EVAP systems vacuum leaks low-pressure turbo leaks intake manifolds cooling / EGR / exhaust systems worn rubber gaskets seals connectors and more. 4.In modern cars many check engine codes are set off by an air/vacuum leak. Quickly dialing in the problem will save you time and money in a shop and help a home mechanic find the problem instead of just changing parts. Smoke Leak Detector ANCEL S100 Output pressure:0.5PSI Output Volume:
