AK4118 Digital Receiver Board Audio Decoder DAC SPDIF to IIS Coaxial Optical USB AES EBU Input Support XMOS Amanero with

Overview This product uses the latest audio dedicated mediation chip AK4118 core design supports 24bit 192K data reception AK4118 as coaxial signal reception has the industrys lowest Jitter Fully optimized by MCU software control the performance is much higher than WM8805 DIR9001 CS8416Case input fiber coaxial SPDIF signal with one way IIS DSD input for XMOS module Italian USB output IIS DSD formatFeatures 1 Use the XMOS module USB to support sampling display 2 The double row 20 pin output interface is compatible with the Italian USB output interface 3 Using OLED to display working status4 All settings are automatically savedInput parameters COAX BNC COAX RCA OPTICAL AES EBU 44 1K 192K 24BITUSB IIS DSD Using XMOS module 44 1K 384K 32BIT DSD64 DSD128 DSD256Output parameters using XMOS module 44 1K 384K 32BIT DSD64 DSD128 DSD256Supply voltage DC 5VBoard size 111 x 49 5mmPackage Includes 1 x DAC boardDisplay and Function Description 1 Input channel Coax Bnc coax RCA USB OPTICAL Aes ebu2 Input signal format PCM DSD Real time display based on input signal 3 Sampling frequency of the input signal Real time display based on input signal 4 MCLK signal output mode configurable NOTE This feature is limited COAX BNC COAX RCA OPTICAL AES EBU input USB input invalid when the USB input the board follows the USB module output signal MCLK 5 Output signal output mode configurable NOTE This feature is limited COAX BNC COAX RCA OPTICA
