AJA OG-12GM openGear 12G-SDI to/from SDI Muxer/DeMuxer
OG-12GM is a compact SDI transport openGear card that enables 12G-SDI to quad-link 3G-SDI and quad-link 3G-SDI to 12G-SDI conversion. The muxer/demuxer supports 4K, UltraHD, 2K, HD and SD workflows and conversions from quad-link SDI signals to single link SDI signals, and vice versa at 12G, 6G, 3G and 1.5G bit rates. Both Square Division (Quadrant) and Two Sample Interleave (2SI) input and output mappings are supported.AJA openGear products are designed for use in high density openGear 2RU frames including AJA's OG-X-FR frame, with industry standard DashBoard software support on Windows, macOS and Linux, offering remote control and monitoring over a PC or local network.openGear CompatibilityThe openGear standard ensures that AJA cards will be compatible with other openGear products from certified openGear partners. With a growing list of products, openGear is the future of rackframe products.Flexible I/OThe modular rear panel allows custom I/O connections per card (included with individual cards).FailsafeThe optional redundant power supply provides a secondary power source in the event of a primary power failure.Ethernet AccessA standard Ethernet connection allows the frame to be accessed via the Dashboard application for overall frame communication. Optional per-card Ethernet access can be installed in the frame for advanced communication with compatible openGear cards.Download DashBoard SoftwareRoss DashBoard software offers quick and convenient configuration and control of openGear cards on macOS, Windows and Linux.AJA Mini-MatrixInformation on the complete line of AJA Rackframes and cards are now available in the Mini-Matrix mobile app on iOS. AJA products are extensive and this app helps you find the right converter for any situation, wherever you are.Individual products have links back to the main AJA website for more details and you can email product information directly from the app. The free AJA Mini-Matrix app for iPad and iPhone is available now in the Apple iTunes Store.
