ADC0809 Module 8-bit 81 Parallel AD Board Analog to Digital Conversion Program Digital Voltmeter

Manual http img banggood com file products 20181018050123SKU994950 docxhttp myosuploads3 banggood com products 20181022 20181022034019SKU994950 ADC0809 zipFeature 1 8 input channels 8 bit A D converter ie resolution is 8 bits 2 It has a conversion start and stop control terminal 3 Conversion time is 100s when the clock is 640kHz 130s when the clock is 500kHz 4 Single 5V power supply5 The analog input voltage range is 0 5V and zero and full scale calibration are not required 6 Operating temperature range is 40 to 85 degrees Celsius7 Low power consumption about 15mW8 Module size is 5 5 x 4 2CM9 The module has a built in precision potentiometer for voltmeter experiment10 The address can be selected by the MCU or the jumper cap can be selected11 It is very convenient to use the pin headers for the input and output ports that are neededPackage includes 1 x ADC0809 Module
