ADC Module 16 Bit I2C GROVE ADS1100 Module 0V to 12V Analog to Digital Converter Development Board
M5Stack
sku: 1549746
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$6.99
Shipping from: China
Description
Description ADC integrated with ADS1100 which is a fully differential 16 bit self calibrating de1ta s1gma A D converter It communicates through an I2C interface which means you can collect AD data thru PortA on M5 core from this unit to enhence your A D performance The I2C address is 0x48 Product Specification COMPLETE DATA ACQUISITION SYSTEM IN A TINY SOT23 6 PACKAGE16 BITS NO MISSING CODESINL 0 0125 of FSR MAXCONTINUOUS SELF CALIBRATIONSINGLE CYCLE CONVERSIONPROGRAMMABLE GAIN AMPLIFIER GAIN 1 2 4 OR 8LOW NOISE 4µVp pPROGRAMMABLE DATA RATE 8SPS to 128SPSINTERNAL SYSTEM CLOCKI2CTM INTERFACEPOWER SUPPLY 2 7V to 5 5VLOW CURRENT CONSUMPTION 90µAAVAILABLE IN EIGHT DIFFERENT ADDRESSESTwo Leg0 compatible holesProduct Size 32 5mm x 24 1mm x 10 2mmProduct weight 5 9gAPPLICATION ECG signal acquisitionBlood pressure measurementDynamometerPackage Included 1x ADC unit1x GROVE Cable1x HT3 96 Male Socket 2 pins Related Link Offical VideoForumDatasheet ADS1100Example 1 forIDEThe below code is incomplete just for usage If you want the complete code please click here Copy to clipboardErrorCopied2 UIFlowIf you want the complete code please click here Schematic PinMap M5Core GROVE A GPIO22GPIO21
