AD8310 0.1-440MHz High-speed H-frequency RF Logarithmic Detector Power Meter For Amplifier

Applications The AD8310 is a high speed voltage output logarithmic amplifier with a detection frequency range of DC to 440MHz Has a very fast response time typically 15 ns and can be used as an ASK demodulator for more than 10 MHz It is also the best choice for higher precision IF signal measurement chips The detector output voltage is equivalent to the input signal dB output and its applications include RSSI transmit power control and pulse detection Parameter 1 Operating frequency 0 1 440 MHz2 Detection slope 24 mV dB3 Detection intercept 108 dBV4 Dynamic range 77dBm to 18 dBm 95 dB 5 Linearity error 0 4 dB6 Response time 15nS7 Output voltage 0 35 2 5V8 Working current 12mA9 Operating voltage 7 15V with LM78L05 regulator chip AD8310 internal block diagram AD8310 detection response curve Package included 1 x AD8310 0 1 440MHz High speed H frequency RF Logarithmic Detector Power Meter
