AC Synchronous Motor 14W Permanent Magnet 2Way High Torsion Central Shaft Bracket XD60KTYZ(2.5rpm/min AC110V)

Item Type: AC Synchronous Motor Model: XD60KTYZ Material: Copper Output Shaft Size: Approx. 7 x 19mm / 0.3 x 0.7in Protection Level: IP20 Insulation Resistance: After the rated operation of the motor under normal temperature and humidity when measuring the insulation resistance between the coil and the motor shell with a DC500V resistance meter it does not exceed 20MΩ Insulation Withstand Voltage: After the rated operation of the motor under normal temperature and humidity 50Hz or 60Hz is applied between the coil shells for a second with a voltage of 1800V there is no abnormality. Temperature Rise: It is normal to install a gear box or equivalent heat sink and conduct rated operation under normal temperature and humidity by using the resistance method to measure the temperature rise of the coil between 75-80℃ Insulation Class: Class E(130℃) Operating Environment Temperature: Motor: -10~+40℃ (no icing) Use Environment Humidity: 85% or less (no condensation) CW/CCW: Yes Speed Adjusted: No Model Voltage(V） Rotating speed（rpm/min） Normal torsion （kgf·cm）long-time working Larger torsion（kgf·cm）intermittent work Power（W） XD60KTYZ AC220V 2.5 38 50 14 10 20 26 14 15 15 20 14 20 12 17 14 AC110V 2.5 38 50 14 10 20 26 14 15 15 20 14 20 12 17 14
