AC/DC Digital Clamp Meter with Temperature Capacitance Measuring Function

The 4000 Counts Digital Clamp Multimeter with Temperature & Capacitance Test & Backlight & Worklight helps you troubleshoot most electrical problems you may have at home. It not only measures AC current, AC/DC voltage and resistance with high accuracy, but also runs temperature test, duty cycle test, on-off test, and diode test. With a convenient clamp design, you can easily clip it anywhere you want. Large LCD screen offers easy-to-read digital displays. Plus, it is built with backlight and worklight for easy use in the dark places.
Feature
Conform to the 13978-92 GB/T digital multi meter standard.
Meet the safety requirements of GB4793.1-1995 (IEC-61010-1).
Measure AC current, AC/DC voltage, and resistance.
Run temperature test, duty cycle test, on-off test, and diode test.
High accuracy, dependable results.
Convenient clamp design, easily clip it anywhere you want.
Large LCD screen offers easy-to-read digital displays.
Built-in backlight and worklight for easy use in the dark places.
Auto power-off function (about 15 minutes).
Auto or manual range setting, data hold function.
Compact and light, easy to carry.
Specifications
Material ABS
DC Voltage 400mV±(0.8%+2); 4V±(0.8%+2); 40V±(0.8%+2); 400V±(0.8%+2); 600V ± (1.0%+2)
Max. input Voltage 600DC or 600V AC Peak
AC Voltage 400mV ±(1.0%+10); 4V ±(1.0%+10); 40V ±(1.0%+10); 400V ±(1.0%+10); 600V ± (1.2%+10)
AC Current 4A ±(3.5%+20); 40A ±(3.0%+10); 400A ±(2.5%+10); 600A ± (1.5%+10)
Resistance 400Ω±(1.2%+2); 4KΩ±(1.2%+2); 40KΩ±(1.2%+2); 400KΩ±(1.2%+2); 4MΩ±(1.2%+2); 40MΩ±(2.0%+5);
Diode 1mV Resolution
Continuity 100mΩ Resolution
Power Supply 3 x AAA Batteries (1.5V) (not included)
Display 3999 Counts
Measuring speed (2.5-3 times)/second
Low-battery Indication Yes
Auto Power-off About 15 Minutes
Working Temperature 0-40℃
Relative Humidity < 80%RH
Dimensions 22L x 8W x 2.5H cm
Package Includes 1 x Digital Clamp Meter, 2 x Set of Test Leads, 1 x User Manual
Package size 24L x 11W x 6H cm
Weight 530g
Certification CE
