AC Current Detector Flexible Current Sensor Stable Non Contact Current Transformer For Electronic Industry

AC Current Detector Flexible Current Sensor Stable Non Contact Current Transformer for Electronic Industry Specification: Item Type: Flexible Coil Current Sensor Model: ETCR150FA Material: ABS Application: Electronics industry power communications equipment manufacturing power grid maintenance Function AC leakage current large current high order harmonic current complex waveform current transient inrush current phase electric energy power Power factor and other detection Detection Method Flexible coil CT: The output signal is the differentiation of current to time. By integrating the output voltage signal it can be truly Input Current Coil Diameter Approx. 7.5mm / 0.3in Range 0A~10000A~higher Resolution 10mA Accuracy Class ±1.0%FS 50Hz/60Hz; 23 degrees Celsius ±2 degrees Celsius below 70% the wire is at the center of the coil Phase Error Less than or equal to 0.1°50Hz/60Hz; 23 degrees Celsius ±2 degrees Celsius Output Interface Approx. 3.5mm / 0.1in audio frequency plug/BNC plug/tap optional cable length: Approx. 2m / 6.6ft Electric Field Interference No hysteresis effect no interference from external electric field Wire Position The tested wire is at the center of the coil and the position error affects Less than or equal to ±0.3%FS Current Frequency 45Hz~70Hz frequency of measured current Response Frequency 0.1Hz~1MHz Line Voltage Line test below AC 1000V Working Temperature and Humidity -20 degrees Celsius ~50 degrees Celsius ; below 80% Storage Temperature and Humidity -10 degrees Celsius ~60 degrees Celsius ; below 70% Dielectric Strength AC 2000V/rms both ends of the coil unlocked and expanded Suitable for Standard CAT IV 600V CAT Ⅲ 1000V Package List: 1 x Coil Current Sensor
