AC 110-220V 500W Air Cooling Spindle Motor with 52mm Clamp and Power Supply Speed Governor

Description: AC 110-220V 500W Air Cooling Spindle Motor with 52mm Clamp and Power Supply Speed Governor Specification: Spindle Motor Product Parameters: Power: 500W Operating voltage: 12-100VDC Idle speed: 2000-12000 rev/min Torque: 0.5NM Insulation resistance:>2 megohms Dielectric strength: 400V Diameter: 52MM Chuck portion length: 45MM Chuck portion diameter: 16MM Motor Length: approx. 190MM High precision spindle run out : 0.01-0.03 Can be used for solid wood PCB engraving drilling and so on. Speed Governor Product Parameters: Input voltage: AC110-AC220V10% 50/60Hz Current limit: 6A The adaptation motor power: 50W-500W Armature output voltage: DC0-100V adjustable Dimensions: 130*100*51mm(L*W*H) Wiring: terminal (convenient) ER11 Chuck Collet Parameters: Material: Carbon Steel Model: ER11 Material: 65MN Apply to: boring, milling, drilling, tapping, sculpture, CNC, spindle machine and other processing. Package Included: 1pc x 500W Spindle Motor 1pc x Speed Governor 1pc x 52MM Mount Bracket 13pcs x ER11 Collet Kindly Remind: -- Ambient air temperature: -10 ~ 40 C. -- The relative humidity of 85% or less, well ventilated. -- Installed in a well-ventilated, no severe impact, no vibration, no explosion of dangerous media and no conductive metal particles of the occasion. Notice: 1. Please allow a bit error due to manual measurement. please make sure you do not mind before you bid. 2. The color may have different as the difference display, pls understand. More Details:
