AAI ORIGINAL English Verison N1201SA N1201SA+ 34.375MHz-2.7GHz UV RF Vector Impedance ANT SWR Antenna Analyzer Meter Tes

Description This instrument has four interfaces single point measurement scanning system information correction and calibrationThe default boot into single point measurement interface Note For the convenience of the user each time calibration correction options will automatically change to the user calibration Meanwhile in order to ensure the integrity of the calibration the calibration process the automatic shutdown function fails the consistent boot Startup and shutdown Hold down the CTRL key off press the power switch button The boot state long press 2S above the switch button after the release the instrument will shut downThe boot state long press 2S above the switch button after the release the instrument will shut downRecommend the use 1 in order to ensure the accuracy of measurement and calibration preheat the instrument at least 15 minutes 2 try to use good quality RF cable and connectors 3 calibrated cable marked to the next may not need to calibrate and direct use 4 test cable process affect the measurement accuracy it is recommended that where possible do not choose too long test cable 5 measurement and calibration before make sure you are not in a strong wireless signal so as to avoid interference caused by inaccurate measurements 6 if the impedance measurements themselves do not understand you can refer to a vector network analyzer instructions and tutorials This instrument is equivalent to a single port vector network analysi
