A7105 Mini Receiver Compatible with FlySky 8CH PPM AFHDS and Hubsan 6CH PPM

A7105 Mini Receiver Compatible with FlySky 8CH PPMAFHDSand Hubsan 6CH PPMDescription Item Name A7105 Miniature ReceiverReception Distance 600 1000mA7105 hardware version compatible with FS also named FlySky 8CH PPM AFHDA or Hubsan 6CH PPM MINI series receiver is a kind of micro receivers newly designed especially for micro remote control models it provides 4 independent output ports and an integrated output port which is for 5A brushed ESC built in 4 brushed ESC you can also connect brushless ESC from outside no need programming operation it has 4 standard servo ports JST1 0mm pitch Besides it supports PPM signal output Features It can still ensure of stable receiver signal when the voltage is as low as 2 5V in this case signal disconnection problem when other receivers working with 1S brushless motor will never happen in future Hardware structure MCU RFIC ANT Size 21 0 12 0 6 5mm not including antenna Weight 1 1g including antenna Supports PPM outputWorking voltage 3 0 5 0VNote short connected A at the back of the board PPM signal output will be achieved Binding The receiver will come to binding mode as soon as it is powered LED light blinks quickly a bright constand LED light shows the binding is finished Package Included 1 x Receiver
