895 High Torque DC Motors 12V 24V 6000RPM Double Ball Bearing for Electric Tool DIY Small Drill Micro Machine

No load Speed: 3000-6000RPM Type: Micro Motor Output Power: 60-80W Commutation: Brushless Voltage: 12 - 24V Model Number: 895 Features: It can also be used as a generator. The faster the speed is the higher the voltage and current will be. 895 the motor shaft diameter is the same as that of the 775 motor 5MM.The new generation of 895 motors help you solve all the deficiencies of the 775. Widely used in micro: cutting machine abrasive belt machine lathe milling machine bench drill electric hand drill polishing machine Buddha bead machine lawn mower wire saw band saw electric mill engraving machine scooter etc. Rated voltage: DC12V -24V. (voltage can be used from 12 to 24V) Support positive inversion (using positive and negative switch or positive negative pole reverse connection). This a low-speed model: 12V 3000 turn maximum torque 5.2 kg 24V 6000 turn maximum torque 10 kg. Motor step height: 4.5mm Motor step diameter: 18mm Motor diameter: 48mm plus magnetic ring 50mm Shaft diameter: 5mm (exactly the same as 775 motor) Length of motor tail shaft: About 6mm Distance between mounting holes: about 29mm Screw diameter of mounting hole: M4 screw and M5 screw Note: Starting current should be more than 10A. It is recommended to use switching power supply or battery like power. It is recommended to use 360W24V15A switching power supply and can not directly use household 220V. Because the shooting environment lighting and angle are different the color of the picture will be somewhat different. Please understand ! Package Including: 1 x 895 DC Motor Product Weight: 500 G / 17.64 Ounces Product Dimensions (L*W*H): 110*50*50 MM / 4.33*1.97*1.97 Inches Package Weight: 501.0 G / 17.67 Ounces Package Dimensions (L*W*H): 115*55*55 MM / 4.53*2.17*2.17 Inches Retail Packaging: Yes General Box
