85mm 120km/h Digital GPS Speedometer Gauge Waterproof Auto Car Truck Marine

Description: Display speed 0-120 kmh High speed recall memory, you can display your highest reached speed at any time. Odometer and trip meter, can be reset any time. Digital compass. Improved Curved glass, less sun glare on sunny day, better visibility Low speed processing from 0 to 5 mph in tenth, perfect for spreader and farming application. Almost instant refresh speed, no more unreasonable lag. Waterproof. Antifogging. Specification: Material: 316L stainless steel front cover, Plastic housing Color: Silver frame White Face / Black frame Black Face / Gold frame White Face / Gold frame Black Face Backlight: Red Diameter: 85mm/3.3" Operating Voltage: 9-32 VDC Operating current: 100mA Operating temperature: -30 - + 75 Storage temperature: -40 - + 85 Note: It must be installed in a 85-87mm hole It require 70mm behind the dash panel Works on 9-32 vDC All mounting hardware is included GPS antenna and wiring harness is included. Fitment: Motorcycle Kart ATV and Side By Side Car Boat Scooter Installation Steps: 1. The hole of 85~87mm is opened on the instrument panel to be installed as shown in figure A, and ensure that the space behind the panel is 70 mm at least. 2. The instrument is put in the instrument panel with the hole as shown in figure B, and the instrument will be locked by F and D accessories. 3. The wiring harness E is inserted in the instrument; as shown in figure G, GPS antenna is connected; as shown in G figure, and electric wire is connected according to the H figure wiring diagram. 4. Turn on the power, and the instrument can begin to work. 5. Technical parameters, working voltage: 9 ~ 32 VDC, working current < 100 mA; Working temperature: - 30 ~ +75 C, storage temperature: - 40 ~ +85 C. SOG:Speed Over Ground; COG: Course Over Ground Package Included: 1 X GPS Speedometer Gauge 1 X GPS Antenna 1 X Wiring Harness (2m)
