6X 16S 48V 30A LiFePo4 Battery Protection Board BMS PCB with Balance for E-Bike EScooter

Maximum charging current: 30A Overcharge detection voltage: 3.75±0.025V Overcharge protection delay: 100±30ms Overcharge release voltage: 3.6±0.05V Battery balance detection voltage: 3.6±0.025V Battery balance release voltage: 3.6±0.05V Battery balance current: 36±5A Overdischarge detection voltage: 2.1±0.08V Overdischarge detection delay: 100ms Overdischarge release voltage: 2.3±0.1V Overcurrent detection voltage: 150mV Overcurrent detection delay: 10ms Size: 80 x 55 x 10mm colour:Silver + green Material:Metal + PCB Connection Using: 1. First connect the B- line to the battery negative terminal (the B- line must be soldered with a short wire) and then connect the flat cable ( connecting the flat cable be to unplug the flat cable from the board) 2. wiring from B- connect B- to the negative electrode of the battery connect the second cable B-1 to the first positive electrode of battery and connect the third cable B-2 to the second positive electrode of battery and the fourth cable B-3 is connected to the third positive electrode of battery...and so on 3. Finally measure whether the battery voltage is to the output voltage of the protection board and the protection board works normally if it is . Package Contents: 6 x - Battery Protection Board 6 x wire Only the above package content other products are not included. Note: Light and different displays may cause the color of the item in the a little different from the real thing. The measurement allowed error is +/- 1-3cm.
