60V/5A Boost LED Driver Module Constant Current Driver For 30W LED DLP Light-curing 3D Printer

Description FYS Boost LED Driver is an economical and easy to use driver with a maximum output of 60V 5A requires you to replace the Rs resistor By default 900mA5 current output is available for 30W LED 10 string 3 modules Features 1 Application for LED Lighting Boost constant current driver TFT LED Backlighting 2 Easy to use drive with up to 60V 5A output 3 Over temperature protection over current protection 4 Excellent line and load regulation thermal shutdown function built in current limit function 5 Easy to use User Manual for ReferenceSpecifications Type LED Drive Board Size 48mm x 38 5mm x 18mm Input voltage DC 5V 32V Output voltage 26V 36V Output current 900mA5 Conversion efficiency 93 max Working temperature 20 80 degree celsius Quantity 1 PC Applications LED lighting Improve constant current driver TFT LED backlightNotice 1 The board will be fever during use about 60 degree Celsius at 900 mA which is normal and need not be worried 2 Do not connect the positive and negative poles of the board input degree Celsiusand output otherwise it will damage the board Package Included 1 x LED Drive Board
