5pcs LCD Display Timer Relay Module DC6-30V Cycle Timing OFF Trigger Delay Switch DC AC Universal Conduction

Features 1 LCD display2 Support high and low level trigger3 Emergency stop function4 Sleep mode Wake up with any button5 Automatically save parameters6 Support UART Set7 Independent of parameters8 Continuously adjustable from 0 01 seconds to 9999 minutes9 Optocoupler isolation Enhanced anti jamming capability Parameters 1 Product Name Delay Relay Module2 Product Number XY LJ023 Working Voltage DC 6V 30V or 5V Micro USB4 Control Current 10A Max 5 Quiescent Current 15mA6 Working Current 50mA7 Working temperature 40 85℃8 Suitable for battery Storage Battery Lithium battery9 Trigger signal source High level trigger 3 0V 24V Low level trigger 0 0V 0 2V switching control passive switch 10 Reverse protection Yes11 Physical dimension 80 38 2 1mm Parameter Description OP Turn On timeCL Turn OFF timeLOP Number of cycles Range is 1 9999tims means unlimited loop Set Parameter Long press keep press button for more than 3second 1 Enter set parameter menu by long press button SET 2 Work mode will flash at first set the working mode Short press the UP DOWN button to set the working mode 3 Short press the SET button to select the working mode and enter the system parameter settings 4 In the system parameter setting interface short press the SET button to switch the system parameters to be modified short long press the UP DOWN button to modify value Note Short press SET is invalid at mode P1 P2 P3 P7 Enter setting interfa
