5pcs JDY-10M 4.0 bluetooth Module Master-Slave Support MESH Networking App Transmission

Product introduction The JDY 10 transmission module is a bluetooth 4 protocol standard the working band is 2 4GHZ range the modulation mode is GFSK the maximum transmission power is 8dB the maximum transmission distance is 50 meters It has the characteristics of low power consumption small size strong signal stable data transmission and so on Product features 1 supports the transmission of Android and IOS mobile phones 2 Supports one to many many to one many to many data transmission and control 3 Supporting network LED lamp 26 scenario mode panel mode brightness white light adjustable speed 4 Supports networking GPIO control one to many many to one many to many 5 can be certified by FCC CR and other standard 6 Supporting networked remote control ultra low power consumption two dry batteries can be used for at least one year 7 support network 4 way PWM control 8 The maximum number of 8 networks is 255 9 supports broadcast and unicast MESH to send data 10 supports BLE master slave operation without master slave switching 11 at least 60 of the smart home application JDY 10M can be competent Product application scope 1 bluetooth networking LED lights one to many many to one mobile phone or remote control many to many control 2 bluetooth network motor pulling applications one to many many to one machine or remote control many to many control 3 network panel switch 86 switch ultra low power consumption 4 network smart home
